Product Model | MR7916A |
Product Name | WLAN 11n USB 1£€♦T1R module |
General | |
Power Consumption | DC3.3V Maximum power ♠$✘dissipation in 80mA |
Size | 18.5mm(L)X15.4mm(W)X3.0mm<δ(H) |
Weight | Approx.:1.4 g |
Operating Temperature | -10~ +70° C ambient temperature |
Storing Temperφ¶®ature | -40 ~ 125°C ambient tempeπγ✘rature |
Operating humidity | 5 to 90 % maximum (non-condensing) |
Standard | 802.11b/g/n, 802.3, 802.3u |
Data Transfer Rate | 1,2,5.5,6,11,12,18,22,24,3£0,36,48,54,60,90,120 and maximum of 150Mbps÷✘ |
Modulation Method | BPSK/ QPSK/ 16-QAM/ 64-φ✘¶βQAM |
Frequency Band | 2.412~2.4835 GHz ISM Band |
Spread Spectrum | IEEE 802.11b: DSSS (Direct Se®≠quence Spread S♦π♥pectrum)； IEEE 802.11g/n:OFDM (Orthog←↕onal Frequency Divi<σ<sion Multiplexing) |
RF Output Power | < 14dBm@11n，< 15dBm@11g，< 19dBm@11b |
Operation Mode | Ad hoc, Infrastructure |
Receiver Sensitivity | 11Mbps-86dBm@8%,54Mbps-73dBm@10%↔,130Mbps，-66dBm@10% |
Operation Range | Up to 180 meters in ope¶☆©n space |
LED | NO |
OS Support | Windows 2000, XP32-64, Vista 32/64, Win7 32/64,Linux,Mac♠±↓±, Android，WIN CE |
Security | WEP, TKIP, AES, WPA, WPA2 |
Interface | USB 2.0 |
